Foxboro FBI10E P0972AJ FBI10E P0972 AJ

Foxboro FBI10E P0972AJ FBI10E P0972 AJ

Product Description:

When the drive mounted HIM is supplied, it will be connected as Adapter 1 (see Adapter in Chapter 2) and visible from the front of the drive. The HIM can be divided into two sections; Display Panel and Control Panel. The Display Panel provides a means of programming the drive and viewing the various

operating parameters. The Control Panel allows different drive functions to be controlled. Refer to Figure and the sections that follow for a description of the panels.Important: The operation of some HIM functions will depend upon drive parameter settings. The default parameter values allow full HIM

functionality.HIM OPERATION When power is first applied to the drive, the HIM will cycle through a series of displays. These displays will show drive name, HIM ID number and communication status. Upon
completion, the Status Display will be shown. This display shows the current status of the drive (i.e.

“Stopped,”“Running,” etc.) or any faults that may be present (“Serial Fault,” etc.). If the HIM software is Series A version3.00

Contact Information:

Contact:Miya ( manager)

Email :sales@mooreplc.com
Q Q: 2851195450
Skype: miyazheng520
Mobile:86-18020776792 ( what's app )

Related Product Recommendation:

The ground conductor of the motor cable should be connected to the drive ground (GRD) terminal directly. Connecting this ground conductor to a cabinet ground point or ground bus bar may cause high frequency current to circulate in the ground system of the enclosure. The motor end of this ground

conductor must be solidly connected to the motor case ground. Shielded or armored cable may be used to guard against radiated emissions from the motor cable. The shield or armor should be connected to the drive ground terminal and the motor ground as outlined in the Grounding section of this Installation

chapter. Common mode chokes are recommended at the drive output to reduce the common mode noise. An RFI filter can be used and in most situations provides an effective reduction of RFI emissions that may be conducted into the main supplylines. If the installation combines a drive with sensitive

devices or circuits,it is recommended that the lowest possible drive PWM frequency be programmed.
