1756-M03SE
The AB 1756-M03SE is a Series A SERCOS interface module that connects the controller to SERCOS interface drives. It has 3 axes available and is compatible with the Kinetix 2000 Servo drive. It uses a single, digital, fiber-optic link that eliminates as many as 18 digital wires per axis. It also lets you control digital drives by using high-speed, real-time serial communication. The drive control modes available with the 1756-M03SE module are position, velocity, and torque.
Before installing this module, it is important to install and ground the ControlLogix chassis it will be connected to first, as well as a ControlLogix power supply, and have the required fiber optic cables wires required for its installation. This is because the wires will be used to connect the drives and the module. The ControlLogix chassis compatible with this module are the 1756-A4, 1756-A7, 1756-A10, 1756-A13, and the 1756-A17. The module can be installed in any available slot of the chassis and has an open-type enclosure.
The module has a SERCOS interface data rate of 4 Mbps or 8 Mbps and can handle a maximum of 3 SERCOS interface drives. At 4 Mbps, the SERCOS cycle time is 0.5 ms for up to 2 drives (but only with Kinetix 6000 drives), 1 ms for up to 4 drives, and 2 ms for up to 8 drives. While at 8 Mbps, the SERCOS cycle time is 0.5 ms for up to 4 drives (but also only with Kinetix 6000 drives), 1 ms for up to 8 drives, and 2 ms for up to 16 drives.
It has a current draw of 2.5 mA at 24V DC and 760 mA at 5.1V DC and a power dissipation of 5 W. The module also has an operating temperature range of 0 to 60 Degrees Celsius and a storage range of -40 to 85 Degrees Celsius. It also has a noncondensing relative humidity of 5% to 95%.
