1756-L62
The 1756-L62 processor module from the ControLogix family of products by AB/Rockwell Automation is a compact and cost-effective device that is mainly used for system control with communication devices and powerful I/O. The users will save a significant amount of money and they can take advantage of the drive’s modularity to build and modify it according to their needs. The 1756-L62 processor module has 4 MB of fixed memory and 4 MB of user memory. Also, this module has 478 KB of I/O memory and an optional nonvolatile memory backup storage for backup through a Compact Flash card. The Compact Flash card with the product code 1784-CD128 is used with this controller and it must be purchased separately. The processor module and controller has Series A and Series B types and it is intended to be used with the 1756 chassis with the product code 1756-A4 / A7 / A10 / A13, or –A17. The controller also features a 1.2 Amps backplane current for 5 Volts DC and 14 mA backplane current for 24 Volts DC.
The 1756-L62 processor module has many features and communication options such as the ControlNet, Remote I/O, EtherNet/IP, and SynchLink networks. The primary communications are achieved through serial ports including the DH-485, DF1 radio modem / DF1 full/half duplex, or the Modbus through Logic and ASCII. The operation of the 1756-L62 offers 3 primary controller tasks for operation and up to 250 controller connections. In addition to that, the controller supports controller redundancy and it offers 100 programs for every task and special event tasks. The 1756-L62 controller operates at a temperature range of 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit) and it has a 10 to 500 Hertz vibration resistance, as well as a tolerance of 5 to 95% of non-condensing humidity. This controller comes in a small package and it weighs only 0.32 kilograms or 0.71 pounds. The supporting batteries for this device are the 1756-BA1 and 1756-BATM.
