| Place of Origin: | USA |
| Brand Name: | AB |
| Certification: | CO.CQ |
| Model Number: | 1756-L55M14 |
Miya(manager)
Email:miya@mvme.cn
Skype:miyazheng520
QQ :2851195450
Tel:0592-5087576
86-18020776792
About 1756-L55M14
Catalog Numbers 1756-L1, 1756-L1M1, 1756-L1M2, 1756-L1M3, 1756-L55, 1756-L55M12, 1756-L55M13, 1756-L55M14, 1756-L55M16, 1756-L55M22, 1756-L55M23, 1756-L55M24, 1756-L61, 1756-L62, 1756-L63, 1756-L64, 1756-L65, 1756-M1, 1756-M2, 1756-M3, 1756-M12, 1756-M13, 1756-M14, 1756-M16, 1756-M22, 1756-M23, 1756-M24, 1784-CF64, 1784-CF128
The controller is placed inside a ControlLogix 1756 chassis and has an open style enclosure. By itself, the controller weighs 0.36 kg or 12.8 oz. Its battery can be replaced with a 1756-BA1 lithium battery. You should remember to replace the controller's battery only when it is necessary. The only serial cables compatible with the 1756-L55M14 controller are either the 1756-CP3 or 1747-CP3 cables.
This controller has the capability to support various communication modes, such as SynchLink, DH-485, Modbus via ladder routine, Universal Remote I/O serial, Data Highway Plus, DeviceNet, ControlNet, and EtherNet/IP. It can also be used in a redundant system as long as you pair it with the same controller and is found within the same ControlNet network.
Backplane currents of 1.25 A at 5.1V DC and 0.14 A at 24V DC are present in the 1756-L55M14 controller. It has a power dissipation of 5.7 W and a thermal dissipation of 19.4 BTU/hr. The controller has been tested to withstand up to 707V DC for 60 s and has a continuous isolation voltage of 30V and is a basic insulation type. It has a conducted RF immunity of 10V rms with 1 kHz sine-wave 80% AM from 150 kHz to 80 MHz.
Operating temperature of the 1756-L55M14 controller ranges from 0 to 60 Degrees Celsius. It also has a storage temperature of -40 to 85 Degrees Celsius. It has a noncondensing relative humidity that ranges from 5% to 95%. The controller also has an operating shock of 30 g and a non-operating shock of 50 g. Its vibration is 2 g at 10 to 500 Hz.
