| Place of Origin | USA |
| Brand Name | AB |
| Certification | CO.CQ |
| Model Number | 1769-OB32 |
Miya(manager)
Email:miya@mvme.cn
Skype:miyazheng520
QQ :2851195450
Tel:0592-5087576
86-18020776792
Industrial automation spare parts failure often causes tens of thousands of business losses to the enterprise.
Moore LIMITED is the world's leading provider of high quality industrial automation spare parts, whether it is a new spare parts, or outdated / discontinued parts, and the technology is dedicated to the normal operation of the enterprise at the best cost, the best quality and efficient way.Whether it is customer service, work efficiency or delivery speed, we always strive for excellence and to be better and better.
1769-OB32
The AB 1769-OB32 compact solid state terminated output module is an output module with a 16-point output, 32 terminations, and a 24V power source. The1769-OB32 has a 20.4-26.4V DC operational range, and an output delay time of 0.5ms (on-mode) or 4ms (off-mode). It is adapted with a 3000mA draw current at 5.1V and a maximum heat dissipation at 4.5W. The 1769-OB32 module is adapted with a maximum off-state leakage current of 1.0 mA at 26.4V and a minimum on-state current of 1.0mA.
It also has an on-state maximum voltage drop of 1.0V DC at 1 A and a maximum current per point of 0.5 A at 60 °C (140 °F), and 1.0 A at 30 °C (86 °F). The 1769-OB32 has a 2.0 A for 10ms surge current, which repeats every 2 seconds. It has a single slot width and is normally mounted on a panel mount or a DIN rail. The module comes with an approximate weight of 450 g (0.992 lb) and in a 118 x 52.5 x 87 mm (4.65 x 2.07 x 3.43 in.) length by breadth by height dimension. It has unique IEC Class 2 reinforced insulation and a 6-module power supply distance. The 1769-OB32 module has a terminal torque screw of 0.68 Nm, a copper wire with 22 by 14 AWG solid wire size, or a 22 by 16 AWG stranded wire size.
