| Place of Origin | USA |
| Brand Name | AB |
| Certification | CO.CQ |
| Model Number | 1771-IXHR |
Miya(manager)
Email:miya@mvme.cn
Skype:miyazheng520
QQ :2851195450
Tel:0592-5087576
86-18020776792
WHAT IS DETAILS ABOUT US ?
Our company has many products in stock,which are immediately available.The warranty is 1 years which apply to all the new products.If you purchase one more parts from us,we can make a discount to you.
We have tens of thousands of industrial automation parts and spare parts storage, ready to ship.
All spare parts and spare parts have one year warranty.
If you order more than 1 items, please contact us, we can offer you discount.
We only use express delivery of spare parts,
If you find other suppliers to offer a lower price for the same product, we would like to offer you a further discount on your price. If you have any other questions, please feel free to contact us.
We await your enquiry.
If you have any question pls do not hesitate to contact us.We can supply all kind of the automaiton parts,if you want to purchase parts pls send the parts model to my mail, I will prompt reply you asa I receive the mail.Hope anyone enquire from us.
The AB 1771-IXHR is a PLC 5 Analog Input Module. It is a high-resolution thermocouple/millivolt input module to transfer input data words from its memory to the PLC processor’s data table and transfer configuration words using block transfer programming. The 1771-IXHR requires a single-slot for installation in a 1771 I/O chassis and needs no external power supply.
The 1771-IXHR module has 8 floating differential inputs for thermocouple or millivolt input ranges which includes types B, E, J, K, T, R, and S thermocouples and ±100 millivolts. Either 8 of the same type of inputs are allowed or 4 inputs each of 2 different types. The 1771-IXHR includes cold junction compensation with a range of 0-60°C and ±0.5°C accuracy. It has a selectable temperature scale of °C or °F with a temperature resolution of 0.1°C or 0.1°F and millivolt resolution of 1µV. It requires a backplane current load of 750mA at 5V and has a channel update time of 25ms per 8 channels. Its wiring is connected to the 1771-WI field wiring arm eliminating the need for disconnecting the wires when replacing the module. The 1771-IXHR has a maximum power dissipation of 4.255W and maximum thermal dissipation of 14.5 BTU/hr. Keying bands must be put between pins 20-22 and pins 24-26 to accept only this module.
The 1771-IXHR module has high and low-temperature alarms that are selectable by the user. It contains a green RUN indicator and a red FLT indicator at the front panel for power and fault status. At power-up, it performs self-diagnostics and reports status. The 1771-IXHR provides open-circuit detection in case the thermocouple fails. It automatically calibrates offset and gain for each channel, eliminating the need of potentiometers.
The 1771 series I/O modules offer digital, analog, and specialrequirement modules. The 1771 I/O modules feature a wide range of: • signal interfaces to ac and dc sensors and actuators. • I/O densities with as many as 32 I/O points per module. • signal levels, including standard analog inputs and outputs and direct thermocouple and RTD temperature inputs. PLC-5 controllers support 1771 I/O over these networks: • Local I/O
