| Place of Origin | USA |
| Brand Name | AB |
| Certification | CO.CQ |
| Model Number | 1747-L543 |
1756-PA75 1756PA75 Allen Bradley AB ControlLogix AC Power Supply
⇒ Click here for good price 1747-L543
| Brand/Manufacturer | AB/USA |
| Part Number | 1747-L543 |
| Alternate Part Number | 1747-L543 |
| Description | SLC 5/04 Processor |
| Dimennsions | 11.4cm x 8.9cm x 4.6cm |
| Weight | 0.5kg |
Product Details
The AB 1747-L543 is an SLC 500 SLC 5/04 processor that has maximum discrete input and output capacities of 4096 each. It has a maximum of 480local analog I/O, as well as a user memory of 64K words, specifically 60K words for data and program and 4K words for data only. It also comes with a Flash EPROM backup memory and 107 programming instructions. The 64 KB RAM of the 1747-L543 processor is battery-backed. The I/O chassis of the 1747-L543 is a maximum of 3, and it has a maximum of 30 I/O module slots. The communication ports present on this processor are a DH+ port and an RS-232 port. The 1747-L543 It also has status LEDs present for forced I/O, run, CPU fault, RS-232, and DH+.
Program scan time of the 1747-L543 processor is 0.9 milliseconds/K on average, its typical I/O scan time is 0.225 milliseconds, and bit execution is 0.37 µs. It also has a program scan hold-up time after the loss of power between 20 milliseconds and 3 seconds, which is also dependent on the loading of the power supply. The 1747-L543 also runs on backplane currents of 1 A at 5 Volts DC and of 125 mA at 24 Volts DC. Its operating shock is 30 G, and it can withstand an acceleration of 2.5 G at 57 to 2000 Hertz and a displacement of 0.015 inches, peak-to-peak, at 5 to 57 Hertz. Its non-condensing relative humidity is between 5 and 95%, its storage temperature is -40 to 85 degrees Celsius, and its operating temperature is 0 to 60 degrees Celsius.
Why choose us
We will provie you the product info and picuture
Large stock, fast delivery
Competitive prices and immdiate quotation
Professional service,professional technical support
Warranty time is one year.
Strict test machine before shipment.
We could help you to get any components which is difficult to get
