| Place of Origin | USA |
| Brand Name | AB |
| Certification | CO.CQ |
| Model Number | 1786-RPCD |
1786-RPCD 1786RPCD Allen Bradley AB ControlNet Coaxial Hub Repeater
⇒ Click here for good price 1786-RPCD
| Brand/Manufacturer | AB/USA |
| Part Number | 1786-RPCD |
| Alternate Part Number | 1786-RPCD |
| Description | DeviceNet Daughtercard |
| Dimennsions |
11x10.7x7cm |
| Weight | 0.18kg |
Product Details
The 1786-RPCD is a coaxial repeater module control net manufactured by AB. It featured a typical repeater distance of 0 to 1 kilometer and it is used with the RG6 copper coaxial cable. The 1786-RPCD coaxial repeater module joins to the RPA/B repeater adapter that supplies it with 5 Volts DC, and it has a backplane current draw of 400mA at 5 Volts DC maximum.
The 1786-RPCD is designed to extend the length of a network, provide a point-to-point topology, or do network media conversion from coaxial media to fiber media and vice versa. The 1786-RPCD operating temperature is 32 to 140 degrees Fahrenheit, a non-operating temperature of 60 degrees, for conducting RF Immunity according to the IEC 61000-4-5 standards. It has a vibration of 5g at 10 to 500 Hertz, with a relative humidity range of 5 to 95% for non-condensing humidity.
The 1786-RPCD is powered by a repeater adapter. The 1786-RPCD makes it easy to connect multiple 1000 meters copper segments to a single repeater adapter (the 1786-RPA). It gives two copper channels and activity status indicators for each channel. The 1786-RPCD consists of two status indicators which are interpreted by the operator to communicate fault situations and if it is powering up, including if there are faults in the data being obtained at the modules. Its delay value is 100n
