2711P-RDK12C 2711PRDK12C AB PanelView Plus 1250 Allen Bradley Keypad

2711P-RDK12C 2711PRDK12C Allen Bradley AB PanelView Plus 1250 Color Keypad Display Module

⇒ Click here for good price 2711P-RDK12C

Product Details

The 2711P-RDK12C PanelView Plus CE 1250 Display Module Kit, is a 12.1 inches full-color display module for the AB PanelView Plus 1250 CE operator interface and it is a standard device which provides users with an easy interface to their machinery for complete control and monitoring. It is used to display information graphically, thereby allowing the operators to quickly understand the status of their applications. The 2711P-RDK12C features a Color Active Matrix LCD screen with a 12.1 inches display size, and it has a display area of 246mm x 184mm with 800 x 600 18-bit color display resolution. It offers users a 50,000-hour rated replaceable backlight with 300cd/m² Nits of screen brightness, and it allows users to easily set and input operational parameters using its Analog Resistive Touchscreen with about 1 million presses of actuation and an operational force of 340G.

Users can also access and input operation parameters through the Stainless-Steel Domed Membrane Keypad with functional (F1 through F20, K1 through K20) keys, Alpha-Numerical keys (0 to 9, ., -, Backspace, Enter, Left and Right tab, Shift, Esc, Ctrl, and Alt), and Navigational keys (Arrow Up and Down). The 2711P-RDK12C has an operational heat dissipation of 240 BTU/hr and its operating temperature range is 32 to 131°F, with a storage temperature range of 13 to 158°F, at 5 to 95% humidity. The 2711P-RDK12C, like other components of the PanelView Plus series, can also be installed at an altitude of 2000m without de-rating. It has an operating shock resistance of 15G for up to 11 milliseconds, with a vibration resistance of 30G for 11 milliseconds, and it is protected by a NEMA Type 12, 13, 4X rated enclosure.
