1756-PA75 1756PA75 AB AB ControlLogix AC Power Supply

Name: 1756-PA75 1756PA75 AB AB ControlLogix AC Power Supply
Brand: MOORE AUTOMATION LIMITED
SKU: 1756-PA75
Availability: InStock

Product Details:

Place of Origin:	USA
Brand Name:	AB
Certification:	CO.CQ
Model Number:	1756-PA75

Detail Information

Place of Origin:

USA

Brand Name:

Certification:

CO.CQ

Model Number:

1756-PA75

Manufacture Year:

2020

Con 6DS1311-8AEtrol System:

1756-PA75

Application:

Nuclear Power Plant

Lead Time:

In Stock

Description:

Weight:

4lbs

Highlight:

High Light

Highlight:

1756-PA75

Power Supply

AB 1756-PA75

Trading Information

Minimum Order Quantity:

Price:

inquiry

Packaging Details:

new and original with factory sealed

Delivery Time:

today

Payment Terms:

T/T

Supply Ability:

10 pieces a day

Product Description

1756-PA75 1756PA75 AB AB ControlLogix AC Power Supply

⇒ Click here for good price 1756-PA75

Brand/Manufacturer	AB/USA
Part Number	1756-PA75
Alternate Part Number	1756-PA75
Description	MOTOR SERVO
Dimennsions	11x14.5x14cm
Weight	1kg

Contact Us

Email: miya@mvme.cn (CLICK)

QQ: 2851195450

Tel: 86-18020776792(CLICK)

Skype:miyazheng520(CLICK)

Product Details

The AB 1756-PA75 Standard AC Power Supply comes with 120 to 240 Volts AC nominal input voltage. This power supply is part of the ControlLogix power supply series and it provides built-in overcurrent protection which is user-supplied at a maximum rate of 15 A. The 1756-PA75 power supply also has a type of reinforced insulation tested at 3,500 Volts DC for 60 seconds. The maximum transformer load of this power supply is 100VA. The voltage isolation of the 1756-PA75 is 250 Volts continuous. The 1756-PA75 has a power consumption of 25 Watts at 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit). This power supply has a power dissipation of 85.3 BTU/hour and a maximum inrush current of 20 A. The input frequency range of the 1756-PA75 is 47 to 63 Hertz. The power supply’s maximum input power is 100VA/100 Watts and the maximum output power is 75 W at 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit).

The AB 1756-PA75 comes with a current capacity at 5.1V of 13 A. This power supply must be mounted on the left side of 1756 chassis and it has a non-replaceable fuse that intended to guard against fire hazards from short circuits. The 1756-PA75 is intended for use in Pollution Level 2 Industry Environments and in excessive Category II applications (as defined in the publication of IEC 60664-1). Note that the 1756-PA75 power supply can operate at an altitude of up to 2000 meters without derating.

1756-PA75 1756PA75 AB AB ControlLogix AC Power Supply 0

Why choose us

1. We will provie you the product info and picuture
2.Large stock, fast delivery
3.Competitive prices and immdiate quotation
4.Professional service,professional technical support
5. Warranty time is one year.
6. Strict test machine before shipment.
7. We could help you to get any components which is difficult to get
