1768-L45S 1768L45S AB AB Compact GuardLogix Controller
⇒ Click here for good price 1768-L45S
| Brand/Manufacturer |
AB/USA |
| Part Number |
1768-L45S
|
| Alternate Part Number |
1768-L45S |
| Description |
MOTOR SERVO |
| Dimennsions |
20.5x18x12.2cm
|
| Weight |
0.65kg |
Contact Us
Email: miya@mvme.cn (CLICK)
QQ: 2851195450
Tel: 86-18020776792(CLICK)
Skype:miyazheng520(CLICK)
Product Details
The AB 1768-L45S is a Compact GuardLogix controller that features a built-in serial port and a key-switch on its front panel that lets you choose a control mode like Run, Program, and Remote. The controller features standard and safety communication options for EtherNet/IP, ControlNet, and DeviceNet. It can carry 3 MB of standard tasks and components and 1 MB of safety tasks and components. It has a 1 RS-232 serial port communication. The 1768-L45S controller can carry up to four 1768 or thirty 1769 modules. The controller does not need a battery replacement and it has up to 3 I/O banks.
The 1768-L45S has a 2.1A back-plane current draw at 24 V DC. The controller has a 9.5 W power dissipation and a 50.4 W power consumption. It comes with an isolation voltage of 30 V DC continuous power with a functional insulation type. The 1768-L45S has been tested to withstand 500V DC for 6 s with the RS-232 isolated communication ports at 38.4 Kbps max. It weighs approximately 0.45 kg with dimensions of 132 x 90 x 122 mm and it can be DIN rail or Panel mounted.
The 1768-L45S controller has an operating temperature 0 - 60°C, a -40 - 85 °C non-operating temperature, and a 5 - 95% relative humidity. It also has an operating vibration of 5g at 10 - 500 Hz, an operating shock of 30 g, and a 50 g non-operating shock.
Why choose us
1. We will provie you the product info and picuture
2.Large stock, fast delivery
3.Competitive prices and immdiate quotation
4.Professional service,professional technical support
5. Warranty time is one year.
6. Strict test machine before shipment.
7. We could help you to get any components which is difficult to get
