1746-IM16 1746IM16 AB AB SLC 16 Point 240V AC Input Module

Name: 1746-IM16 1746IM16 AB AB SLC 16 Point 240V AC Input Module
Brand: MOORE AUTOMATION LIMITED
SKU: 1746-IM16
Availability: InStock

Product Details:

Place of Origin:	USA
Brand Name:	AB
Certification:	CO.CQ
Model Number:	1746-IM16

Detail Information

Place of Origin:

USA

Brand Name:

Certification:

CO.CQ

Model Number:

1746-IM16

Manufacture Year:

2020

Con 6DS1311-8AEtrol System:

1746-IM16

Application:

Nuclear Power Plant

Lead Time:

In Stock

Description:

Weight:

4lbs

Highlight:

High Light

Highlight:

1746-IM16

240V AC Input Module

AB 1746-IM16

Trading Information

Minimum Order Quantity:

Price:

inquiry

Packaging Details:

new and original with factory sealed

Delivery Time:

today

Payment Terms:

T/T

Supply Ability:

10 pieces a day

Product Description

1746-IM16 1746IM16 AB AB SLC 16 Point 240V AC Input Module

⇒ Click here for good price 1746-IM16

Brand/Manufacturer	AB/USA
Part Number	1746-IM16
Alternate Part Number	1746-IM16
Description	MOTOR SERVO
Dimennsions	24.5x16.5x5.5cm
Weight	0.45kg

Contact Us

Email: miya@mvme.cn (CLICK)

QQ: 2851195450

Tel: 86-18020776792(CLICK)

Skype:miyazheng520(CLICK)

Product Details

The 1746-IM16 SLC 500 Digital AC Input Module by AB is an input (AC) module with sixteen 200-240V AC inputs and is fitted into any available SLC 500 I/O chassis using an RTB (Removable Terminal Block). It has 16 points per common and an input operating voltage of 170-265V AC at 47-63Hz. It has a backplane current rating of 0.085A at 5V DC and an electrical signal delay of 35ms for ON and 45ms for OFF state around its input points. It has an OFF-state rating of 50V AC voltage loss and 2mA maximum OFF-state current.

The 1746-IM16 has an input current (nom) of 12mA around each input points and has a maximum surge current of 1.6A, which can last for a maximum duration of 0.5ms. It has a maximum power dissipation of 0.35W at each point and the total heat dissipated by the module is at 6W. It provides voltage isolation between input terminals and control logic tested at 1500V and is NEMA standard ICS 2-230-rated for noise immunity. The operating temperature of the 1746-IM16 ranges between 0 and 60 °C (32 and 140 °F) at 5-95% non-condensing humidity limits and it has a non-operational storage temperature of -40 and 85 °C (-40 and 185 °F). The 1746-IM16 has an operational shock withstand of 30G and can sustain an operating 2.5G vibration at 57-200Hz.

1746-IM16 1746IM16 AB AB SLC 16 Point 240V AC Input Module 0
