1766-L32AWA 1766L32AWA AB AB MicroLogix 1400 32 Point Controller
⇒ Click here for good price 1766-L32AWA
| Brand/Manufacturer |
AB/USA |
| Part Number |
1766-L32AWA
|
| Alternate Part Number |
1766-L32AWA |
| Description |
MOTOR SERVO |
| Dimennsions |
21.5x13x10cm
|
| Weight |
0.7kg |
Contact Us
Email: miya@mvme.cn (CLICK)
QQ: 2851195450
Tel: 86-18020776792(CLICK)
Skype:miyazheng520(CLICK)
Product Details
The AB 1766-L32AWA is a part of the MicroLogix 1400 Programmable Logic Controller series. The 1766-L32AWA controller requires 120-240V AC input power and has battery-backed RAM. It supports 32 digital I/O points with Twenty (20) digital 120V AC inputs and 12 Relay outputs. It can be expanded by connecting with up to seven 1762 expansion I/O modules.
The 1766-L32AWA measures 3.5 x 7.08 x 3.43 in. and weighs 2 lbs. For communication, it has an isolated RS-232/485 port, an Ethernet port, and a non-isolated RS-232 port. It also has an embedded real-time clock to provide a reference for applications that need time-based control. It is programmable with RSLogix 500/Micro programming software (Version 8.1 and above). For installation, it has Panel or DIN-Rail mounting options with its open enclosure. It is suitable for use in a clean, dry industrial environment with circuits not exceeding Over Voltage Category II. The 1766-L32AWA controller has various superior features over its predecessors. The Ethernet port comes with a DNP3 protocol support and with a web server and an email capability. It has 2 Serial ports that support the DH485/DF1/Modbus RTU/DNP3/ASCII protocol. It has up to 6 embedded 100-kHz high-speed counters (only on controllers with DC inputs). It also has 20 KB memory for user programs and data.
Our service
100% full New - Original Factory Seal
Warranty: 12 months
Package: Original packing with cartons
Delivery time: Shipped in 3 days after payment
