Allen Bradley Modules 1775-GA 1775-GA AB 1775GA Peripheral Comm Module effective service

Allen Bradley Modules 1775-GA 1775-GA AB 1775GA Peripheral Comm Module effective service

Product Description:

ULTRA 100 and 200 drives are feature-rich, high-performance drives that offer the flexibility to handle a wide range of applications. You can set up the ULTRA 100/200 drives as indexing drives, velocity servo drives, stepper drives, or master encoder followers. With the DeviceNet option, you can remotely commission and reprogram ULTRA 100 drives. In addition, you can use the ULTRA 100/200
drives host command protocol to set up multiple drives. Available in seven power ranges, theULT RA100/200 drives can be mated to four high-performance brushless servo motor lines. Ultra Master software, a Windows-based interface, provides you with a familiar programming environment and a powerful commissioning tool for all ULTRA 100/200 drives.ULTRA 200 positioning drives deliver full-featured flexibility and impressive power and performance. Each ULTRA 200 drive provides:115 to 230V AC single phase input (single phase or three phase for the 75 amp version, three phase only for the 150 amp version) Phase-to-phase and phase-to-ground short circuit protection An internal resistive shunt A built-in auxiliary AC input (to power logic only) Built-in power supplies (including 24V I/O supply)—no external sourcerequired (except AC line) The ability to drive sinusoidal AC brushless motors An DC bus available externally for power leveling or for use of shared power supplies

Related Product Recommendation:

Product's Character:

When the drive mounted HIM is supplied, it will be connected as Adapter 1 (see Adapter in Chapter 2) and visible from the front of the drive. The HIM can be divided into two sections; Display Panel and Control Panel. The Display Panel provides a means of programming the drive and viewing the various
operating parameters. The Control Panel allows different drive functions to be controlled. Refer to Figure and the sections that follow for a description of the panels.Important: The operation of some HIM functions will depend upon drive parameter settings. The default parameter values allow full HIM
functionality.HIM OPERATION When power is first applied to the drive, the HIM will cycle through a series of displays. These displays will show drive name, HIM ID number and communication status. Upon
completion, the Status Display will be shown. This display shows the current status of the drive (i.e. “Stopped,”“Running,” etc.) or any faults that may be present (“Serial Fault,” etc.). If the HIM software is Series A version3.00
