Allen Bradley Modules 1785-BCM 1785 BCM AB 1785BCM COMMUNICATION MODULE Excellent Working Condition

Product Description

Allen Bradley Modules 1785-BCM 1785 BCM AB 1785BCM COMMUNICATION MODULE Excellent Working Condition

Product Description:

ULTRA 100 and 200 drives are feature-rich, high-performance drives that offer the flexibility to handle a wide range of applications. You can set up the ULTRA 100/200 drives as indexing drives, velocity servo drives, stepper drives, or master encoder followers. With the DeviceNet option, you can remotely commission and reprogram ULTRA 100 drives. In addition, you can use the ULTRA 100/200
drives host command protocol to set up multiple drives. Available in seven power ranges, theULT RA100/200 drives can be mated to four high-performance brushless servo motor lines. Ultra Master software, a Windows-based interface, provides you with a familiar programming environment and a powerful commissioning tool for all ULTRA 100/200 drives.ULTRA 200 positioning drives deliver full-featured flexibility and impressive power and performance. Each ULTRA 200 drive provides:115 to 230V AC single phase input (single phase or three phase for the 75 amp version, three phase only for the 150 amp version) Phase-to-phase and phase-to-ground short circuit protection An internal resistive shunt A built-in auxiliary AC input (to power logic only) Built-in power supplies (including 24V I/O supply)—no external sourcerequired (except AC line) The ability to drive sinusoidal AC brushless motors An DC bus available externally for power leveling or for use of shared power supplies

Related Product Recommendation:

Product's Character:

Two serial connectors to simplify RS-485 multi-dropping and host communications Several analog or digital command interfaces: Indexing (absolute with the Homing feature, incremental, or
registration)10 Volt analog interface—position, velocity, or torque control Presets (from one to eight binary inputs)—torque or velocity control Quadrature encoder digital interface—electronic gearing position follower Step/Direction digital interface—position control CW/CCW (step up/step down) interfaceposition control Operating mode override—alternate movement interface Host command digital interface The ULTRA 100/200 drives host command protocol provides optional drive configuration using the drive serial communications interface. This powerful feature allows your controller to access all of the drive digital controls using sequences of ASCII characters. The protocol includes error checking to
ensure the integrity of the transmitted commands. In installations that have multiple axes, up to 32 ULTRA 100/200 drives can be addressed by a host computer. These drives communicate with the host
computer using a four-wire RS-485 serial interface. The host command protocol includes specific drive addressing, which allows the host to communicate with all the connected drives concurrently.
