Allen Bradley Modules 1785-LTB 1785 LTB AB 1785LTB Processor 6K Word SRAM 512 I/O

Allen Bradley Modules 1785-LTB 1785 LTB AB 1785LTB Processor 6K word SRAM 512 I/O

Product Description:

Two serial connectors to simplify RS-485 multi-dropping and host communications Several analog or digital command interfaces: Indexing (absolute with the Homing feature, incremental, or
registration)10 Volt analog interface—position, velocity, or torque control Presets (from one to eight binary inputs)—torque or velocity control Quadrature encoder digital interface—electronic gearing position follower Step/Direction digital interface—position control CW/CCW (step up/step down) interfaceposition control Operating mode override—alternate movement interface Host command digital interface The ULTRA 100/200 drives host command protocol provides optional drive configuration using the drive serial communications interface. This powerful feature allows your controller to access all of the drive digital controls using sequences of ASCII characters. The protocol includes error checking to
ensure the integrity of the transmitted commands. In installations that have multiple axes, up to 32 ULTRA 100/200 drives can be addressed by a host computer. These drives communicate with the host
computer using a four-wire RS-485 serial interface. The host command protocol includes specific drive addressing, which allows the host to communicate with all the connected drives concurrently.

Related Product Recommendation:

Product's Character:

Bulletin 1305 drive parameter data can be programmed and displayed using PLC’s, SLC’s or other logic controllers using an optional Bulletin 1203 Communication Module. The amount of information that can be transferred between the drive and controller is determined by the DIP switch settings on theCommunication Module. Table B.1 illustrates the dip switch settings for Bulletin 1203-GD1 (Remote I/O) communication modules. Dip switch settings for other communication modules will be similar. Refer
to the appropriate communication module user manual for details.Important: 1305 drives with firmware revisions FRN1.01 and FRN1.02 are not compatible with Bulletin 1203 Communication Modules. If connected, an error message will be indicated. The red fault status and amber SCANport status LED’s on the front of the module will flash simultaneously.
