Allen Bradley Modules 1791-16AC 179116AC AB 1791 16AC I/O MODULE

Product Description

Allen Bradley Modules 1791-16AC 179116AC AB 1791 16AC I/O MODULE

Product Description:

Appendix B provides information about the Block Transfer messages supported by the Remote I/O communications module. In this appendix, you will read about the following: Block transfer status word.
Setting up data files for block transfer messages.Examples of block transfer messages. Block transfer quick reference. Important: This appendix provides detailed examples of block transfer messages. For information about block transfer messages, also refer to Chapter 5.Chapter 1 provides an overview of the
Remote I/O communications module (1203-GD1 module, 1203-GK1 module, and 1336-GM1 board). In this chapter, you will read about the following:Function of the module.Features of the module. Compatible SCANport products and programmable controllers. Parts and hardware of the module. Steps for setting up the module.Required tools and equipment.Description of the Remote I/O Communications Modules The Remote I/O communications module is an optional interface designed to provide a direct, digital link between an AB programmable controller and any one AB SCANport product. A module is required for each product that you want to connect to Remote I/O. There are three types of Remote I/O communications modules

Related Product Recommendation:

Product's Character:

The Remote I/O communications module allows a SCANport product to look and act like a Remote I/O chassis when connected to a programmable controller. Data contained in the input/output image table is transferred between the programmable controller by the Remote I/O scanner, the same as with any Remote I/O chassis. You control the location of data transferred by setting the rack address and
starting group. You control the amount of data by setting the DIP switches on SW3. Important: Thecommunications module does not scale the data that is transferred. Consequently, all scaling of the data must be done in the controller. Refer to the user manual for your SCANport product for details on
device units. Important: The Remote I/O to SCANport conversion is asynchronous. Data sent to the adapter for transfer to the drive must be maintained until the drive has received data.DIP switches on SW3 determine how the data contained in the programmable controller I/O image table is used in the drive. Figure shows an I/O image table.
