Allen Bradley Modules 1441-PEN25-BAT 1441 PEN25 BAT AB 1441PEN25BAT

Product Description

Allen Bradley Modules 1441-PEN25-BAT 1441 PEN25 BAT AB 1441PEN25BAT

Product Description:

The ground conductor of the motor cable should be connected to the drive ground (GRD) terminal directly. Connecting this ground conductor to a cabinet ground point or ground bus bar may cause high frequency current to circulate in the ground system of the enclosure. The motor end of this ground

conductor must be solidly connected to the motor case ground. Shielded or armored cable may be used to guard against radiated emissions from the motor cable. The shield or armor should be connected to the drive ground terminal and the motor ground as outlined in the Grounding section of this Installation

chapter. Common mode chokes are recommended at the drive output to reduce the common mode noise. An RFI filter can be used and in most situations provides an effective reduction of RFI emissions that may be conducted into the main supplylines. If the installation combines a drive with sensitive

devices or circuits,it is recommended that the lowest possible drive PWM frequency be programmed.

Email :sales@mooreplc.com
Q Q: 2851195450
Skype: miyazheng520
Mobile:86-18020776792 ( what's app )

Related Product Recommendation:

Product's Character:

Advanced multi-processor design for leading-edge velocity loop bandwidth, fully digital current, velocity, and position loopsLarge-scale integration with custom ASICs and IPMs for performance and reliabilityA 16-bit A/D convertor for precise velocity command input Flash memory for simple field upgrades A

personality module to store setup parameters and simplify drive replacement Reduced component count for reliability Internally-shielded filters for electromagnetic compatibility (EMC) Four dedicated I/O plus eight user-selectable, optically isolated digital inputs and outputs (sourcing/active high):Two dedicated

inputs Two dedicated outputs Four user-selectable inputs Four user-selectable outputs Two analog inputs for external current limit Two analog outputs for variable monitoring or torque sharing The purpose of this manual is to provide the user with the necessary information to install, program, start up and

maintain the Bulletin 1305 drive. To assure successful installation and operation, the material presented must be thoroughly read and understood before proceeding. Particular attention must be directed to the ATTENTION and Important statements contained within.
